Enclosure heat exchanger “BOX FAN”

Climate control equipment


Standard (Internal mounting) - UL listed

OC-17-A100/OC-17-A200 RoHS compliedUL complied

OC-17

Lateral mounting
Cooling output(50/60Hz) 8/10 W/K

OC-12-A100/OC-12-A200 RoHS compliedUL complied

OC-12

Lateral mounting
Cooling output(50/60Hz) 10/12 W/K

OC-15-A100/OC-15-A200 RoHS compliedUL complied

OC-15

Lateral mounting
Cooling output(50/60Hz) 10/12 W/K

OC-28-A100/OC-28-A200 RoHS compliedUL complied

OC-28

Lateral mounting
Cooling output(50/60Hz) 16/20 W/K

OC-31-A100/OC-31-A200 RoHS compliedUL complied

OC-31

Lateral mounting
Cooling output(50/60Hz) 16/20 W/K

OC-30-A100/OC-30-A200 RoHS compliedUL complied

OC-30

Lateral mounting
Cooling output(50/60Hz) 25/30 W/K

OC-20-A100/OC-20-A200 RoHS compliedUL complied

OC-37

Lateral mounting
Cooling output(50/60Hz) 34/43 W/K

OC-37-A100/OC-37-A200 RoHS compliedUL complied

OC-37

Lateral mounting
Cooling output(50/60Hz) 35/42 W/K

OC-40-A100/OC-40-A200 RoHS compliedUL complied

OC-40

Lateral mounting
Cooling output(50/60Hz) 60/80 W/K

Standard (External mounting) - UL listed

OC-17S-A100/OC-17S-A200 RoHS compliedUL complied

OC-17S

Lateral mounting
Cooling output(50/60Hz) 8/10 W/K

OC-12S-A100/OC-12S-A200 RoHS compliedUL complied

OC-12S

Lateral mounting
Cooling output(50/60Hz) 10/12 W/K

OC-15S-A100/OC-15S-A200 RoHS compliedUL complied

OC-15S

Lateral mounting
Cooling output(50/60Hz) 10/12 W/K

OC-28S-A100/OC-28S-A200 RoHS compliedUL complied

OC-28S

Lateral mounting
Cooling output(50/60Hz) 16/20 W/K

OC-31S-A100/OC-31S-A200 RoHS compliedUL complied

OC-31S

Lateral mounting
Cooling output(50/60Hz) 16/20 W/K

OC-30S-A100/OC-30S-A200 RoHS compliedUL complied

OC-30S

Lateral mounting
Cooling output(50/60Hz) 25/30 W/K

OC-20S-A100/OC-20S-A200 RoHS compliedUL complied

OC-20S

Lateral mounting
Cooling output(50/60Hz) 34/43 W/K

OC-37S-A100/OC-37S-A200 RoHS compliedUL complied

OC-37S

Lateral mounting
Cooling output(50/60Hz) 35/42 W/K

OC-40S-A100/OC-40S-A200 RoHS compliedUL complied

OC-40S

Lateral mounting
Cooling output(50/60Hz) 60/80 W/K

ページ最上部へ

Compact

OC-153H-A100/OC-153H-A200 RoHS compliedUL complied

OC-153H

Internal lateral mounting/UL listed/Small sized heat exchanger
Cooling output(50/60Hz) 9/11 W/K

OC-201L

OC-201L

Internal lateral mounting/Small sized heat exchanger
Cooling output(DC24V±10%) 6.5 W/K

OC-0810HIL/0820HIL

OC-0810HIL/0820HIL

Partially internal mounting/Small sized heat exchanger
Cooling output(50/60Hz) 6.5/8 W/K

ページ最上部へ

CE-marked

OC-12-A200-CE RoHS compliedCE declared

OC-12-A200-CE

Internal lateral mounting/CE-marked
Cooling output(50/60Hz) 10/12 W/K

OC-28-A200-CE RoHS compliedCE declared

OC-28-A200-CE

Internal lateral mounting/CE-marked
Cooling output(50/60Hz) 16/20 W/K

OC-37-A200-CE RoHS compliedCE declared

OC-37-A200-CE

Internal lateral mounting/CE-marked
Cooling output(50/60Hz) 35/42 W/K

OC-12S-A200-CE RoHS compliedCE declared

OC-12S-A200-CE

External lateral mounting/CE-marked
Cooling output(50/60Hz) 10/12 W/K

OC-28S-A200-CE RoHS compliedCE declared

OC-28S-A200-CE

External lateral mounting/CE-marked
Cooling output(50/60Hz) 16/20 W/K

OC-37S-A200-CE RoHS compliedCE declared

OC-37S-A200-CE

External lateral mounting/CE-marked
Cooling output(50/60Hz) 35/42 W/K

ページ最上部へ

Thermostats

OTH-05 RoHS compliedCE declared

OTH-05

Separately mounted thermostat

Output contact rating/AC240V
Setting range/OPEN (OFF) 29±3℃ CLOSE (ON) 37±4℃

OTH-03 RoHS compliedCE declared

OTH-03

Separately mounted thermostat

Output contact rating(V)/[AC] 250/115/60/48/24 [DC] 60/48/24
Setting range/+5 to+60℃(variable)

ページ最上部へ

Consumable parts

Guards,Filters and Fans

各種ガード、フィルタ

BOX FAN consumable parts

Filter guard/Fin guard/Filter/Fan
