Insulation caps and covers

Wiring accessories


Liquid-tight Insulation tubes OA-QW

"OA-QW with connection guide, single wire system" RoHS complied

Single wire system

Convenient for straight cable splicing and insulating with screw tight waterproof. No post-taping is required.
【Applications】For relaying power cable of welding mahine.

"OA-QW with connection guide, 2 wire systems" RoHS complied

2 wire systems

【Applications】For lead wire joints of sensor limit switches.

"OA-QW with connection guide, 3 wire systems" RoHS complied

3 wire systems

【Applications】For relaying signal wires.

"OA-QW with connection guide, 4 wire systems" RoHS complied

4 wire systems

【Applications】For relaying three-phase motors. For relaying reduced wiring systems.

"OA-QW without connection guide" RoHS complied

Without connection guide

No taping work required! For liquid-tight insulation at wire connecting parts.
【Applications】
For insulation and protection from water at various splicing parts or in place of junction boxes for wiring on sensors or limit switches.

"OA-QW Termination splice type" RoHS complied

Termination splice type

Straight cable splicing for heavy duty wiring with terminating capability
【Applications】
All heavy duty splicing with terminating requirement for large-sized welding machines, electric discharge equipment, laser beam machines or construction equipment, while providing excellent insulation and waterproof sealing.

Fitting Bracket RoHS complied

Termination splice type

Option for Liquid-tight Insulation tubes

Connecting guide RoHS complied

Termination splice type

Option for Liquid-tight Insulation tubes

ページ最上部へ

Insulation caps and covers

Insulation cap for round crimp terminals OA-QM Product Family RoHS complied

OA-QM Product Family

No post-taping is required! Labor saving is approximately 1/10 of conventional method. Connection change is also quick and easy.
【Applications】
Insulates ring to ring terminal connections such as motor and bulb terminals.

"Insulation cap for round crimp terminals" OA-QCM Product Family RoHS complied

OA-QCM Product Family

Post-taping is not required! Insulation is ensured simply by slipping the cable in. Connection change is also quick and easy.
【Applications】
Insulates ring to ring terminal connections such as motor and bulb terminals.
Option:QCM-8C・10C

"Multiple connection insulation cap" OA-QTM Product Family RoHS complied

OA-QTM Product Family

Convenient, terminal block and box in one. Eliminates troublesome taping work.
【Applications】
Handy for various splicing and insulation purposes such as motor wiring and cables on machineries and test equipment.

"Multiple connection insulation cap" OA-QTM 633,834 RoHS complied

OOA-QTM 633,834

For branching power supply up to 600V, 15A and power lines.
Applicable to 3 to 6 ports or 4 to 8 ports by combination of shorting bars
【Applications】
For branching connections in wire-saving systems.
For branching in power supply circuit or wiring in parallel synchronizedoperation.

"Multiple connection insulation cap" OA-QTM 844 RoHS complied

OOA-QTM 844

For branching power supply up to 600V, 30A and power lines.
Applicable to 4 to 8 ports by combination of shorting bars
【Applications】
For branching power circuit and wiring parallel synchronized operation of motors.


Option: QTM Protection Cap RoHS complied

Option:QTM Protection Cap

Wearing the protection cap prevents dust between a cabtyre cable and wires.

Option: QTM 2-point Fastener RoHS complied

Option:QTM 2-point Fastener

To provide more secure fitting QTM.

"Insulation cover for metric screw terminals" BISCAP RoHS complied

BISCAP

Simply press them in to install and obtain insulations.
Cost and labor savings are obvious.
【Applications】
Secures insulating protection for variety of meter terminals or built-in exposed terminals within control boxes.

"Insulation cover for micro switches" RoHS complied

Micro switches

A must for micro-switch protections. "MICROCASE" ensures the safeness to switch itself in addition to its terminals.
【Applications】
Insulation as well as protective retaining the cables on micro-switches.
(applicable for inch-based or P=25.4mm switches)

ページ最上部へ

Antidust cover for e-CON connector e-CON Cap OA-QP

Antidust cover for e-CON connector RoHS complied

OA-QM Product Family

For keeping dust away from e-CON connectors!!
【Applications】
For protecting e-CON connectors from dust
